Ultra cool Dry Block Calibrator -100~25°C

Ultra cool Dry Block Calibrator -100~25°C

The Measurax L2390 Ultra-Cool Dry Block Calibrator sets the standard as the most accurate and stable cold-temperature dry block available on the market. It is specifically designed for applications requiring stringent quality control and adherence to regulatory complianc



Category: Tags: ,

Description

The Measurax Ultra Low Temperature Dry Block Calibrator (-100°C) is engineered to deliver reliable and uniform temperature control for precision calibration applications. Designed with advanced thermal stability technology, this calibrator ensures accurate measurement performance even in demanding industrial environments.

It is ideal for calibration laboratories, pharmaceutical industries, HVAC systems, food processing units, and research facilities requiring low-temperature validation and testing.

  • Temperature Range: Ambient to -100°C
  • High Accuracy & Stability
  • Fast Cooling Performance
  • Uniform Temperature Distribution
  • Digital PID Temperature Controller
  • Portable & Compact Design
  • Suitable for RTD & Thermocouple Calibration

DASHEET : Ultra cool dry block Calibrator L2390

Additional information

Temperature range at 25 °

-90°C ( -100/-80 also Available) to 25°C at 25°C
Control accuracy PID

± 0.1 ˚C
Resolution

0.1 ˚C
Thermal Instability

±0.015 °C at -100°C
±0.020 °C at -90°C
±0.016 °C at -50°C
±0.011 °C at 25°C
Thermal Non Uniformity (Radi al)

±0.080°C at -100°C
±0.070 °C at -90°C
±0.052 °C at -50°C
± 0.021°C at 25°C
Stabilization Time/settling time

10 minutes after set point is achieved
Cooling Time

70 Min.( Ambient to -90°C ) @25°C
45 Min.( -90 to -100 °C ) @25°C
Heating Time

15 Min.( -100 to 25°C ) @25°C
Environmental Condition

Environmental Condition
Power Supply/Power Consumption

230 V AC , 50 Hz 300 Watt
Weight

10.00 Kgs(approx.)
Construction Size (H x W x D)

Construction Size (H x W x D)
Insert Length

120mm
Insert OD

28mm
